BIM & takeoff

Adopt a CDE approval preset

Run the CDE setup wizard, adopt a ready-made ISO 19650 review flow in one click, tailor it to your team, then confirm the go-live gate is actually satisfied.

4 steps8 minGeneral contractorBIM / digital consultancyProject / construction management firm

How it works, step by step

4 steps across the platform - what you do at each one, and why it matters.

1

Run the CDE setup wizard

CDE

Open Set up CDE and step through the naming convention, suitability codes and the four functional roles - Author, Reviewer, Approver, Viewer.

Why: The wizard is resumable and saves as you go, so a half-finished setup never loses progress. Fixing who holds each role first is what makes the gate a step later mean something.

InProject teamOutRole assignments
2

Adopt an approval preset

CDE

In the CDE page's Approval presets card, pick Issue for review, Comment and return, or Review and publish, and click Adopt. This clones the preset into a route that belongs to your project.

Why: The tenant-wide preset stays read-only and reusable by every other project; adopting makes your own copy the one you can actually change, without anyone else's flow moving under them.

InRole assignmentsOutEditable review route
3

Tailor the route to your team

Approval routes

In Approval routes, open your cloned route and adjust it: rename it, change an approver's role, add a second step, or set an SLA - then dry-run it before anyone routes real work through it.

Why: A preset is a starting point, not a straitjacket. The dry run proves your tailored route still terminates at approved before it gates a real container.

InEditable review routeOutTuned review route
4

Confirm the go-live gate

CDE

Back in the CDE page, check the go-live readiness scorecard. It only allows inviting the whole team once the workflow has actually been exercised, not just configured on paper.

Why: A CDE that looks configured but has never moved a container through its gates is a showroom, not a working environment. The gate is what stops a team finding that out the hard way.

InTuned review routeOutGo-live readiness
